◆技術性因素 Main technical parameters (請從上到下閱覽有大量量 裝修案例圖片供決定性)
器機型號規格 Model |
STR-9070/9080 |
STR-1010 |
工作上艙長寬比 Internal size(mm) |
900×800×650 |
1000×1000×790 |
裸機寬度 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
交流電源 Power |
220V 50Hz |
220V 50Hz |
刷卡機照航燈具燈 Machine floodlight |
一壺60W防爆型燈 |
220V 13W環保節能燈管 |
輥筒受力 Roller bearing |
10-30Kg |
10-30Kg |
溶合器三相電機 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
離心分離設備排風量 Separator air volume |
8.5m3/min |
8.5m3/min |
壓縮的冷空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
機氣重量體積 Weight |
320kg |
380 kg |
◆食品特征 Product features
1. 設置新奇、外觀畢節、組成科學實驗、基本操作有利;
2. 自功的控制自功噴砂,掌握定時任務噴砂,點動準確定位等功能鍵;
3. 輥子外徑及噴槍規模可通過用戶的需求設計打造打造;
4. 既可以自動的,又可自動的,噴砂口感好,一機二用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆不適用人群之內 Applicable scope
采用來巨大小軸類零件的帶有大量手動或會自動噴砂,隨后:電木質品、小螺絲、朔膠制
品、鈕扣、拉鏈設計、亞克力、機氣零安全裝置等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
